Acer Aspire 5100 RAM Replacement

Сложность

Moderate

Шаги

4

Необходимое время

Нет оценки

Введение

This guide has been updated! Read the new guide here.

Replace the RAM in your Acer Aspire 5100.

Инструменты

  1. fMp5QsOxxtvCJfuH

    • Remove the four screws securing the RAM/thermal module cover.

  2. oe3dvxQc5yrAriIw

    • Lift and remove the thermal module cover away from the Aspire 5100.

  3. vfcIP1AVumlE1Aud

    • Release the tabs on each side of the chip by simultaneously pushing each tab away from the RAM.

    • These tabs lock the chip in place and releasing them will cause the chip to "pop" up.

  4. ZZxGACIodwb3jWXd

    • After the RAM chip has popped up, pull it straight out of its socket.

    • Repeat this process if a second RAM chip is installed.

Заключение

To reassemble your device, follow these instructions in reverse order.
