Kenwood DRV-N520

This is the Page for the Kenwood DRV-520 Dash cam. Here you can find troubleshooting to diagnose your problem, and guides to help you replace faulty parts if you need to.

Check out this device’s troubleshooting page:

Kenwood DRV-N520 Troubleshooting

Manual Download (PDF):

http://manual.kenwood.com/en_contents/at...

Manufacturer’’s Website:

https://www.kenwood.com/usa/car/dashboar...

Image sensor: 1/3 inch color CMOS

Recording Angles: Horizontal: 117 degrees, Vertical: 63 degrees

Lens: Wide-angle, F-number 2.0

Recording Resolution: Video max: 2.98 megapixels

Frame rate: 27fps

Recording Media: Micro SDHC card, 8GB-32GB (class 6 or more)

G-sensor Sensitivity: -4.0G to +4.0G (in .01 G increments)

Power Voltage: 14.4V (8.5 to 16V)

Current Consumption: 400mA

Temperature Range: -10C to 60C

Dimensions: W:79mm, H:22mm D:48mm

Weight: 77g (excluding cord)

Video:

• Recording format: MOV
• Video: H.264
• Audio: Linear PCM

Image:

• JPEG (max: 2304x1296)
